Offered in various configurations, RO4003C laminates utilize both 1080 and 1674 glass fabric styles with all configurations meeting the same laminate electrical performance specification. RO4003C laminates provide tight control on dielectric constant (Dk) and low loss while utilizing the same processing method as standard epoxy/glass but at a fraction of the cost of conventional microwave laminates. Unlike PTFE based microwave materials, no special through-hole treatments or handling procedures are required.
RO4003C materials are non-brominated and are not UL 94 V-0 rated. For applications or designs requiring a UL 94 V-0 flame rating, RO4835™ and RO4350B™ laminates do meet this requirement.
· Dk of 3.38 +/- 0.05
· Dissipation factor of 0.0027 at 10 GHz
· Low Z-axis coefficient of thermal expansion at 46 ppm/°C
· Ideal for multi-layer board (MLB) constructions
· Processes like FR-4 at lower fabrication cost
· Designed for performance sensitive, high volume applications
· Competitively priced
| RO4003 Parameter | Numerical value |
| Board materal | RO4003c |
| Dielectric constant (εr) | 3.55 |
| Dielectric thikness | 0.254 mm (0.010 in) |
| Copper cladding |
1 OZ
|
| Copper cladding type | double sided |
| Dissipation factor (tan δ) |
0.0027 0.0021
|
| Board size (metric) | 305 x 457 mm |
| Board size (inch) |
12 x 18 in
|
| Service area | Around the world |
Dickson Circuit Co.,Ltd has a 17 year history of producing high frequency PCB.
We cooperates with many well-known companies such as Samsung, Osram, Philips, and China Southern Power Grid.
The quality is guaranteed and the price is very affordable.
Just give me a Gerber file, and I will definitely give you a satisfactory product.
If you are interested, please feel free to contact me at any time.
